Part# DMHBSRR1SET
Specifications
PCD 114.3-5H
Hub bolt effective thread 26.0 mm
Hub bolt thread pitch M12 x 1.25 mm
Hub bolt spline diameter 14.3 mm
Compatible Models
Compatible (R)PS13/S14/S15/R32/R33/HR34/C34/C35/WGC34
Not compatible Not compatible with 4WD vehicles / Not compatible with GT-R drive shafts / Not compatible with ER34 aluminum knuckles
*This is a competition-only part. Installing it may increase noise and vehicle vibration compared to the original equipment.
*For S13/180SX models, a separate 5-hole rotor from an S14/S15 turbo model is required.
